型号意义
产品特点
1、电机、水泵一体，潜入水中运行，安全可靠。
2、对井管、扬水管无特殊要求(即：钢管井、灰管井、土井等均可使用；在压力许可下、钢管、胶管、塑料管等均可作扬水管使用)。
3、安装、使用、维护方便简单，占地面积小、不需建造泵房。
4、结构简单、节省原材料。
工作条件
1．QJ型深井潜水泵电源要求：
(1)额定频率为50赫兹，电机端额定电压应保证为380+5％伏的三相交流电源(若用户电压为660伏时需特殊定货)。
(2)变压器负载功率不应超过其容量的75％。
(3)变压器距井较远时，应考虑输电线线压降，对功率大于45KW的电机，要求变压器到井口距离不超过20米，大于20米时，要求输电线规格比配电缆规格大两个等级，并考虑线压降。
2．水质要求：
(1)一般无腐蚀性清水。
(2)水中含砂量不大于0.01％(质量比)。
(3)酸碱度PH值在6．5-8．5范围内。
(4)水中氯离子含量不大于400毫克／升。
(5)硫化氢含量不大于1．5毫克／升。
(6)水温不高于20℃。
3．井筒要求：
正直、光滑、不得有凸起或井管错位现象，井内径不小于相应的机座号。
性能参数
| 型号 | 流量(m3/h) | 扬程(m) | 电机功率(KW) | 额定电流A | 出水管直径（m） |
| 1OOQJ2-50/10 | 2 | 40 | 0.75 | 2 | 40 |
| 100QJ2-70/14 | 70 | 1.1 | 3.1 |
| 100QJ2-80/16 | 80 | 1.1 | 3.1 |
| 100QJ2-100/20 | 100 | 1.5 | 3.8 |
| 100QJ2-110/22 | 110 | 1.5 | 3.8 |
| 100QJ2-140/28 | 140 | 1.5 | 3.8 |
| 100QJ2-150/30 | 150 | 2.2 | 5.6 |
| 1OOOJ2-160/32 | 160 | 2.2 | 5.6 |
| 100QJ2-190/38 | 190 | 2.2 | 5.6 |
| 1OOOJ2-200/40 | 200 | 3 | 7.3 |
| 100QJ3.2-40/6 | 2.2 | 40 | 0.75 | 2 | 40 |
| 1OOOJ3.2-54/8 | 54 | 0.75 | 2 |
| 100QJ3.2.68/10 | 68 | 1.1 | 3.1 |
| 100QJ3.2-72/11 | 72 | 1.1 | 3.1 |
| 1OOQJ3.2-99/15 | 99 | 1.5 | 3.8 |
| 1OOQJ3.2-108/16 | 108 | 2.2 | 5.6 |
| 100QJ3.2-135/20 | 135 | 2.2 | 5.6 |
| 1OOQJ3.2-144/21 | 144 | 3．O | 7.3 |
| 100QJ3.2-170/25 | 170 | 3 | 7.3 |
| 100QJ3.2-230/34 | 230 | 4 | 10.26 |
| 100QJ5-24/6 | 5 | 24 | 0.75 | 2 | 40 |
| 100QJ5-36/9 | 36 | 1.1 | 3.1 |
| 100QJ5-48/12 | 48 | 1.5 | 3.8 |
| 100QJ5-64/16 | 64 | 2.2 | 5.6 |
| 100QJ5-72/18 | 72 | 2.2 | 5.6 |
| 100QJ5-88/22 | 88 | 3 | 7.3 |
| 100QJ5-96/24 | 96 | 3 | 7.3 |
| 1OOQJ5-108/27 | 108 | 3 | 7.3 |
| 100QJ5-128/32 | 128 | 4 | 10.26 |
| 100QJ5-164/41 | 164 | 5.5 | 13.74 |
| 100QJ5-220/55 | 220 | 7.5 | 18.5 |
| 1OOQJ8-15/3 | 8 | 15 | 0.75 | 2 | 50 |
| 1OOQJ8-20/4 | 20 | 1.1 | 3.1 |
| 1OOQJ8-30/6 | 30 | 1.5 | 3.8 |
| 1OOQJ8-40/8 | 40 | 99 | 5.6 |
| 1OOQJ8-50/10 | 50 | 3 | 7.3 |
| 1OOOJ8-60/12 | 60 | 3．O | 7.3 |
| 1OOQJ8-70/14 | 70 | 3 | 7.3 |
| 1OOQJ8-85/17 | 85 | 4 | 10.26 |
| 1OOQJ8-95/19 | 95 | 5.5 | 13.74 |
| 1OOQJ8-100/20 | 100 | 5.5 | 13.74 |
| 1OOQJ8-110/22 | 110 | 5.5 | 13.74 |
| 1OOOJ8-135/27 | 135 | 7.5 | 18.5 |
| 1OOQJ8-150/30 | 150 | 7.5 | 18.5 |
| 1OOQJ10-48/1o | 10 | 48 | 2.2 | 5.6 | 50 |
| 1OOQJ10-60/13 | 60 | 3 | 7.3 |
| 1OOQJ10-80/17 | 80 | 4 | 10.26 |
| 1OOQJ10-108/22 | 108 | 5.5 | 13.74 |
| 1OOQJ10-130/27 | 130 | 7.5 | 18.5 |
| 1OOQJ15-34/10 | 15 | 34 | 3．O | 7.3 | 50 |
| 100QJ15-52/14 | 52 | 4 | 10.26 |
| 1OOQJ15-58/18 | 58 | 5.5 | 13.74 |
| 1OOQJ15-82/24 | 82 | 7.5 | 18.5 |
| 150QJ5-85/12 | 5 | 85 | 3 | 7.9 | 50 |
| 150QJ5-100/14 | 100 | 3 | 7.9 |
| 150QJ5-150/21 | 150 | 4 | 10.26 |
| 150QJ5-200/28 | 200 | 5.5 | 13.74 |
| 150QJ5-250/35 | 250 | 7.5 | 18.5 |
| 150QJ5-300/42 | 300 | 9.2 | 22.12 |
| 150QJ10-50/7 | 10 | 50 | 3 | 7.9 |
| 150QJ10-78/11 | 78 | 4 | 10.26 |
| 150QJ10-100/14 | 10 | 100 | 5.5 | 13.74 | 50 |
| 150QJ10-128/18 | 128 | 7.5 | 18.5 |
| 150QJ10-150/21 | 150 | 7.5 | 18.5 |
| 150QJ10-178/25 | 178 | 9.2 | 22.12 |
| 150QJ10-200/28 | 200 | 11 | 26.28 |
| 150QJ10-250/35 | 250 | 13 | 30.87 |
| 150QJ10-300/42 | 300 | 15 | 35.62 |
| 150QJ20-26/4 | 20 | 26 | 3 | 7.9 |
| 150QJ20-33/5 | 33 | 3 | 7.9 |
| 150QJ20-39/6 | 39 | 4 | 10.26 |
| 150QJ20-46/7 | 46 | 5.5 | 13.74 |
| 150QJ20-52/8 | 52 | 5.5 | 13.74 |
| 150QJ20-59/9 | 59 | 5.5 | 13.74 |
| 150Q220-65/10 | 65 | 7.5 | 18.5 |
| 150QJ20-72/11 | 72 | 7.5 | 18.5 |
| 150QJ20-78/12 | 78 | 7.5 | 18.5 |
| 150QJ201-85/13 | 85 | 9.2 | 22.12 |
| 150QJ20-91/14 | 91 | 9.2 | 22.12 |
| 150QJ20-98/15 | 98 | 9.2 | 22.12 |
| 150QJ20-104/16 | 104 | 11 | 26.28 |
| 150QJ20-111/17 | 111 | 11 | 26.28 |
| 150QJ20-117/17 | 117 | 13 | 30.87 |
| 150QJ20-124/19 | 124 | 13 | 30.87 |
| 150QJ20-130/20 | 130 | 13 | 30.87 |
| 150QJ20-137/21 | 137 | 15 | 35.62 |
| 150QJ20-143/22 | 143 | 15 | 35.62 |
| 150QJ20-150/23 | 150 | 15 | 35.62 |
| 150QJ20-156/24 | 156 | 15 | 35.62 |
| 150Q220-163/25 | 163 | 15 | 35.62 |
| 150QJ25-24/3 | 25 | 24 | 3 | 7.9 | 65 |
| 150QJ25-32/4 | 32 | 4 | 10.3 |
| 150QJ25-40/5 | 25 | 40 | 5.5 | 13.7 | 65 |
| 150QJ25-48/6 | 48 | 5.5 | 13.7 |
| 150QJ25-56/7 | 56 | 7.5 | 18.5 |
| 150QJ25--64/8 | 64 | 7.5 | 18.5 |
| 150QJ25-72/9 | 72 | 9.2 | 18.5 |
| 1509325-80/10 | 80 | 9.2 | 22.1 |
| 150QJ25-88/11 | 88 | 11 | 26.3 |
| 150QJ25-96/12 | 96 | 11 | 26.3 |
| 150QJ25-104/13 | 104 | 13 | 30.9 |
| 150QJ25-112/14 | 112 | 13 | 30.9 |
| 150QJ25-120/15 | 120 | 15 | 35.6 |
| 150QJ25-128/16 | 128 | 15 | 35.6 |
| 150QJ25-136/17 | 136 | 18.5 | 44 |
| 150QJ25-144/18 | 144 | 18.5 | 44 |
| 150QJ25-152/19 | 152 | 18.5 | 44 |
| 150QJ32-18/3 | 32 | 18 | 3 | 7.9 | 65 |
| 150QJ32-24/4 | 24 | 4 | 10.26 |
| 150QJ32-30/5 | 30 | 5.5 | 13.74 |
| 150QJ32-36/6 | 36 | 5.5 | 13.74 |
| 150QJ32-42/7 | 42 | 7.5 | 18.5 |
| 150QJ32-54/9 | 54 | 9.2 | 22.12 |
| 150QJ32-66/11 | 66 | 11 | 26.28 |
| 150QJ32-72/12 | 72 | 13 | 30.87 |
| 150QJ32-84/14 | 84 | 13 | 30.87 |
| 150QJ32-90/15 | 90 | 15 | 35.62 |
| 150QJ32-96/16 | 96 | 15 | 35.62 |
| 150QJ32-108/18 | 108 | 18.5 | 44 |
| 150QJ50-6/1 | 50 | 6 | 3 | 7.9 | 80 |
| 150QJ50-12/2 | 12 | 4 | 10.26 |
| 150QJ50-18/3 | 18 | 5.5 | 13.74 |
| 150QJ50-24/4 | 24 | 7.5 | 18.5 |
| 150Qj50-30/5 | 30 | 9.2 | 22.12 |
| 型号 | 流量(m3/h) | 扬程
(m) | 电机功率(KW) | 额定电流(A) | 出水管直径
mm |
| 150QJ50-36/6 | 50 | 36 | 9.2 | 22.12 | 80 |
| 150QJ50-42/7 | 42 | 11 | 26.28 |
| 150QJ50-48/8 | 48 | 13 | 30.87 |
| 150QJ50-54/9 | 54 | 15 | 35.62 |
| 150QJ50-60/10 | 60 | 18.5 | 44 |
| 150QJ50-66/11 | 66 | 18.5 | 44 |
| 150QJ50-72/12 | 72 | 18.5 | 44 |
| 200QJ20-40/3 | 20 | 40 | 4 | 10.1 | 50 |
| 200QJ20-54/4 | 54 | 5.5 | 13.6 |
| 200QJ20-67/5 | 67 | 7.5 | 18 |
| 200QJ20-81/6 | 81 | 7.5 | 18 |
| 200QJ20-93/7 | 93 | Q9 | 21.7 |
| 200QJ20-108/8 | 108 | 11 | 25.8 |
| 200QJ20-121/9 | 121 | 13 | 29.8 |
| 200QJ20-133/10 | 20 | 133 | 15 | 33.9 | 50 |
| 200QJ20-148/11 | 148 | 15 | 33.9 |
| 200QJ20-175/13 | 175 | 18.5 | 41.6 |
| 200QJ20-202/15 | 202 | 22 | 48.2 |
| 200QJ20-243/18 | 243 | 25 | 54.5 | 65 |
| 200QJ20-270/20 | 270 | 30 | 65.4 |
| 2000320-297/22 | 297 | 30 | 65.4 |
| 200QJ20-338/25 | 338 | 37 | 79.7 |
| 200QJ20-350/26 | 350 | 37 | 79.7 |
| 200QJ20-363/27 | 363 | 37 | 79.7 |
| 200QJ20-400/30 | 400 | 45 | 96.9 |
| 200QJ20-450/34 | 450 | 45 | 96.9 |
| 200QJ32-26/2 | 32 | 26 | 4 | 10.1 | 65 |
| 200QJ32-39/3 | 39 | 5.5 | 13.6 |
| 200QJ32-52/4 | 52 | 7.5 | 18 |
| 200QJ32-65/5 | 65 | 11 | 25.8 |
| 200QJ32-78/6 | 78 | 11 | 25.8 |
| 200QJ32-91/7 | 91 | 13 | 29.8 |
| 200QJ21-104/8 | 104 | 15 | 33.9 |
| 200QJ32-130/10 | 130 | 18.5 | 41.6 |
| 200QJ32-156/12 | 156 | 25 | 54.5 |
| 200QJ32-195/15 | 195 | 30 | 65.4 |
| 200QJ32-234/18 | 234 | 37 | 79.7 |
| 200QJ32-247/19 | 247 | 37 | 79.7 |
| 200QJ32-260/20 | 260 | 45 | 96.9 |
| 200QJ32-286/22 | 286 | 45G | 96.9 |
| 200QJ40-26/2 | 40 | 26 | 5.5 | 13.6 |
| 200QJ40-39/3 | 39 | 7.5 | 18 |
| 200Q340-52/4 | 52 | q9 | 21.7 |
| 200QJ40-65/5 | 65 | 11 | 25.8 |
| 200QJ40-78/6 | 78 | 15 | 33.9 |
| 200QJ40-104/8 | 104 | 18.5 | 41.6 |
| 200QJ40-117/9 | 117 | 22 | 48.2 |
| 200QJ40-143/11 | 143 | 25 | 54.5 |
| 200QJ40-169/13 | 40 | 169 | 30 | 65.4 | 65 |
| 200QJ40-182/14 | 182 | 37 | 79.7 |
| 200QJ40-208/16 | 208 | 37G | 79.7 |
| 200QJ40-234/18 | 234 | 45G | 96.9 |
| 200QJ40-247/19 | 247 | 45G | 96.9 |
| 200QJ50-13/1 | 50 | 13 | 4 | 10.1 | 80 |
| 200QJ50-26/2 | 26 | 5.5 | 13.6 |
| 200QJ50-39/3 | 39 | 9.2 | 21.7 |
| 200QJ50-52/4 | 52 | 11 | 25.8 |
| 200QJ50-65/5 | 65 | 15 | 33.9 |
| 200QJS0-78/6 | 78 | 18.5 | 41.6 |
| 200QJ50-91/7 | 91 | 22 | 48.2 |
| 200QJ50-104/8 | 104 | 25 | 54.5 |
| 200QJ50-117/9 | 117 | 30 | 65.4 |
| 200QJ50-130/1O | 130 | 30 | 65.4 |
| 200QJ50-156/12 | 156 | 37 | 79.7 |
| 200QJ50-182/14 | 182 | 45G | 96.9 |
| 200QJ50-195/15 | 195 | 45G | 96.9 |
| 200QJ63-12/1 | 63 | 12 | 4 | 10.1 | 80 |
| 200QJ63-24/2 | 24 | 7.5 | 18 |
| 200QJ63-36/3 | 36 | 11 | 25.8 |
| 200QJ63-48/4 | 48 | 15 | 33.9 |
| 200QJ63-60/5 | 60 | 18.5 | 41.6 |
| 200QJ63-72/6 | 72 | 99 | 48.2 |
| 200QJ63-84/7 | 84 | 9氏 | 54.5 |
| 200QJ63-96/8 | 96 | 30 | 65.4 |
| 200QJ63-108/9 | 108 | 30 | 65.4 |
| 200QJ63-120/10 | 120 | 37 | 79.7 |
| 200QJ63-144/12 | 144 | 45 | 96.9 |
| 200QJ80-11/1 | 80 | 11 | 4 | 10.1 | 100 |
| 200QJ80-22/1 | 22- | 7.5 | 18 |
| 200QJS0-33/3 | 33 | 11 | 25.8 |
| 200QJ80-44/4 | 44 | 15 | 33.9 |
| 200QJ80-55/5 | 55 | 18.5 | 41.6 |
| 200QJ80-66/6 | 80 | 66 | 22 | 48.2 | 100 |
| 200QJ801-77/7 | 77 | 30 | 65.4 |
| 200QJ80-88/8 | 88 | 37 | 79.7 |
| 2000J80-99/9 | 99 | 37 | 79.7 |
| 200QJ80-121/11 | 121 | 45 | 96.9 |
| 250QJ32-138/6 | 32 | 138 | 22 | 47.9 | 65 |
| 250QJ32-161/7 | 161 | 25 | 53.8 |
| 250QJ321-184/8 | 184 | 30 | 64.2 |
| 250QJ32-207/9 | 207 | 37 | 77.8 |
| 250QJ32-230/10 | 230 | 37 | 77.8 |
| 250QJ32-253/11 | 253 | 45 | 94.1 |
| 250QJ32-276/12 | 276 | 45 | 94.1 |
| 250QJ32-300/13 | 300 | 55G | 114.3 | 80 |
| 250QJ32-322/14 | 322 | 55G | 114.3 |
| 250QJ32-345/15 | 345 | 63G | 130.9 |
| 250QJ32-368/16 | 368 | 63G | 130.9 |
| 250QJ32-391/17 | 391 | 63G | 130.9 |
| 250QJ32-414/18 | 414 | 75G | 152.3 |
| 250QJ32-437/19 | 437 | 75G | 152.3 |
| 250QJ32-460/20 | 460 | 75G | 152.3 |
| 250QJ32-483/21 | 483 | 90G | 182.8 |
| 250QJ32-506/22 | 506 | 90G | 182.8 |
| 250QJ32-529/23 | 529 | 90G | 182.8 |
| 250QJ32-552/24 | 552 | 90G | 182.8 |
| 250QJ32-575/25 | 575 | 100G | 203.1 |
| 250QJ32-598/26 | 598 | 100G | 203.1 |
| 250QJ50-20/1 | 50 | 20 | 5.5 | 13.6 | 65 |
| 250QJ50-40/2 | 40 | 9.2 | 21.7 |
| 250QJ50-60/3 | 60 | 13 | 29.8 |
| 250QJ50-80/4 | 80 | 18.5 | 41.6 |
| 250QJ50-100/4 | 100 | 22 | 47.9 | 80 |
| 250QJ50-120/6 | 120 | 25 | 53.8 |
| 250QJ50-140/7 | 140 | 37 | 77.8 |
| 250QJ50-160/8 | 160 | 37 | 77.8 | 80 |
| 250QJ50-180/9 | 180 | 45 | 94.1 |
| 250QJ50-200/10 | 200 | 45 | 94.1 |
| 2509350-220/11 | 220 | 55G | 114.3 |
| 250QJ50-240/12 | 240 | 55G | 114.3 | 100 |
| 250QJ50-260/13 | 260 | 63G | 130.9 |
| 250QJ50-280/14 | 280 | 63G | 130.9 |
| 250QJ50-300/15 | 300 | 63G | 130.9 |
| 250QJ50-320/16 | 50 | 320 | 75G | 152.3 |
| 250Qj50-340/17 | 340 | 90G | 182.8 |
| 250QJ50-360/18 | 360 | 90G | 182.8 |
| 250QJ50-380/19 | 380 | 1OOG | 203.1 |
| 250QJ50-400/20 | 400 | 100G | 203.1 |
| 2509ff50-420/21 | 420 | 110G | 223.4 |
| 250QJ50-440/22 | 440 | 110G | 223.4 |
| 250QJ50-460/23 | 460 | 110G | 223.4 |
| 250QJ50-480/24 | 480 | 110G | 223.4 |
| 250QJ50-500/25 | 500 | 110G | 223.4 |
| 250QJ80-20/1 | 80 | 20 | 7.5 | 18 |
| 250QJ80-40/9, | 40 | 15 | 33.9 |
| 250QJ80-60/3 | 60 | 22 | 47.9 |
| 250QJ80-80/4 | 80 | 30 | 64.2 |
| 250QJ80-100/5 | 100 | 37 | 77.8 |
| 250QJ801-120/6 | 120 | 45 | 94.1 |
| 250QJ80-140/7 | 140 | 55 | 114.3 |
| 250QJ80-160/8 | 160 | 55 | 114.3 |
| 250QJ80-180/9 | 180 | 63 | 130.9 |
| 250QJ80-200/10 | 200 | 75 | 152.3 |
| 250QJ80-220/11 | 220 | 90G | 182.8 |
| 250QJ80-240/12 | 240 | 90G | 182.8 |
| 250QJ80-260/13 | 260 | 90G | 182.8 |
| 型号 | 流量(m3/h) | 扬程(m) | 电机功率(KW) | 额定电流(A) | 出水管直径
mm |
| 250QJ80-280/14 | 80 | 280 | 100G | 203.1 | 100 |
| 250QJ80-300/15 | 300 | 110G | 223.4 |
| 250QJ80-320/16 | 320 | 110G | 223.4 |
| 250QJ100-18/1 | 100 | 18 | 7.5 | 18 |
| 250QJ100-36/2 | 36 | 15 | 33.9 |
| 250Q5100-54/3 | 54 | 25 | 53.8 |
| 25093100-72/4 | 72 | 30 | 64.2 |
| 250QJ100-108/6 | 108 | 45 | 94.1 |
| 250QJ100-126/7 | 126 | 55 | 114.3 |
| 250QJ100-144/8 | 144 | 63 | 130.9 |
| 250QJ100-162/9 | 162 | 75 | 152.3 |
| 250QJ100-198/11 | 198 | 90G | 182.8 |
| 250QJ100-216/12 | 216 | 100G | 203.1 |
| 250QJ100-234/13 | 234 | 110G | 223.4 |
| 250QJ100-252/14 | 252 | 110G | 233.4 |
| 250QJ125-16/1 | 125 | 16 | 9.2 | 21.7 | 125 |
| 250QJ1251-32/2 | 32 | 18.5 | 41.6 |
| 250QJ125-48/3 | 48 | 25 | 53.8 |
| 250QJ125-64/4 | 64 | 37 | 77.8 |
| 250QJ125-80/5 | 80 | 45 | 94.1 |
| 250QJ125-96/6 | 96 | 55 | 114.3 |
| 250QJ125-112/7 | 112 | 63 | 130.9 |
| 250QJ125-128/8 | 128 | 75 | 152.3 |
| 250QJ125-144/9 | 144 | 90G | 182.8 |
| 250QJ125-160/10 | 160 | 90G | 182.8 |
| 250QJ125-176/11 | 176 | 100G | 203.1 |
| 250QJ125-192/12 | 192 | 110G | 223.4 |
| 250QJ125-208/13 | 208 | 110G | 223.4 |
| 250QJ140-15/1 | 140 | 15 | 9.2 | 21.7 |
| 250QJ140-30/2 | 30 | 18.5 | 41.6 |
| 250QJ140-45/3 | 45 | 30 | 64.2 |
| 250QJ140-60/4 | 140 | 60 | 37 | 77.8 | 125 |
| 250QJ140-75/5 | 75 | 45 | 94.1 |
| 250QJ140-90/6 | 90 | 55 | 114.3 |
| 250QJ140-105/7 | 105 | 63 | 130.9 |
| 250QJ140-120/8 | 120 | 75 | 152.3 |
| 250QJ140-150/10 | 150 | 90G | 182.8 |
| 250QJ140-165/11 | 165 | 100G | 203.1 |
| 250QJ140-180/12 | 180 | 110G | 223.4 |
| 250QJ160-15/1 | 160 | 15 | 11 | 25.8 |
| 250QJ160-30/2 | 30 | 22 | 47.9 |
| 250QJ160-45/3 | 45 | 37 | 77.8 |
| 250QJ160-60/4 | 60 | 45 | 94.1 |
| 250QJ160-75/5 | 75 | 55 | 114.3 |
| 250QJ160-90/6 | 90 | 63 | ．130.9 |
| 250QJ160-105/7 | 105 | 75 | 152.3 |
| 250QJ160-120/8 | 120 | 90 | 182.8 |
| 250QJ160-135/9 | 135 | 90G | 182.8 |
| 250QJ160-150/10 | 150 | 100G | 203.1 |
| 300QJ200-20/1 | 200 | 20 | 18.5 | 41.6 | 125 |
| 300QJ200-40/2 | 40 | 37 | 77.8 |
| 300QJ200-60/3 | 60 | 55 | 114.3 |
| 300QJ200-80/4 | 80 | 75 | 152.3 |
| 300QJ200-100/5 | 100 | 90G | 182.8 |
| 300QJ200-120/6 | 120 | 110G | 220.8 |
| 300QJ200-140/7 | 140 | 125G | 249.5 |
| 300QJ200-160/8 | 160 | 140G | 277.8 |
| 300QJ230-20/1 | 230 | 20 | 22 | 47.9 | 150 |
| 300QJ230-40/2 | 40 | 45 | 94.1 |
| 300QJ230-60/3 | 60 | 75 | 154 |
| 300QJ230-80/4 | 80 | 90G | 183.8 |
| 300QJ230-100/5 | 100 | 90G | 183.8 |
| 300QJ250-15/1 | 250 | 15 | 18.5 | 41.6 | 150 |
| 300QJ250-30/2 | 30 | 37 | 77.8 |
| 300QJ250-24/1 | 24 | 30 | 64.2 |
| 300QJ250-48/2 | 48 | 55 | 114.3 |
| 300QJ250-72/3 | 72 | 90G | 183.8 |
| 300QJ320-28/1 | 320 | 28 | 45 | 94.1 | 200 |
| 300QJ320-56/2 | 56 | 75 | 152.3 |
| 300QJ320-84/3 | 84 | 125G | 249.5 |
| 350QJ250-25/1 | 250 | 25 | 30 | 64.2 | 150 |
| 350QJ250-50/2 | 50 | 63 | 130.9 |
| 350QJ250-75/3 | 75 | 90G | 182.8 |
| 350QJ250-100/4 | 100 | 125G | 249.5 |
| 350QJ320-30/1 | 320 | 30 | 45 | 94.1 | 200 |
| 350QJ320-60/2 | 60 | 90G | 182.8 |
| 350QJ320-90/3 | 90 | 145 | 277.8 |
| 350QJ320-20/1 | 20 | 30 | 64.2 |
| 350QJ320-40/2 | 40 | 63 | 130.9 |
| 350QJ500-20/1 | 500 | 20 | 45 | 94.1 |
| 350QJ500-40/1 | 40 | 90G | 182.8
|
注：由于产品技术改进参数可能有一定变化，公司不另行通知，请咨询公司技术部门索取新数据。
