IRG型立式热水循环泵

产品详情

产品概述

    上武流体IRG型立式热水泵属于单级单吸立式管道离心泵,适用于冶金、化工、纺织、木材加工、造纸以及饭店、浴室、宾馆等锅炉高温热水增压循环输送以及城市住房采暖循环用泵,使用温度150℃以下。

型号意义

例如:IRG50-160(I)A

ISG-立式单级管道离心泵

IRG-立式单级热水管道离心泵

GRG-立式单级热水管道离心泵

IHG-立式单级不锈钢化工泵

YG-单级单吸管道油泵

50-泵进、出口公称直径(mm)

160-叶轮名义外径(mm)

I-流量分类

A-叶轮经第一次切割

产品特点

1.热水泵为立式结构,进出口口径相同,且位于同一中心线上,可象阀门一样安装于管路之中,外形紧凑美观,占地面积小,建筑投入低,如加上防护罩则可置于户外使用。

2.叶轮直接安装在电机的长轴上,轴向尺寸短,结构紧凑,泵与电机轴承配置合理,能有效地平衡泵运转产生的径向和轴向负荷,从而保证了泵的运行平稳,振动小、噪音低。

3.轴封采用机械密封或机械密封组合,采用进口钛合金密封环、中型耐高温机械密封和采用硬质合金材料,耐磨密封,能有效地延长机械密封的使用寿命。

4.热水管道泵安装检修方便,无需拆动管路系统,只要卸下泵联体座螺母即可抽出全部转子部件。

5.可根据使用要求即流量和扬程的需要采用泵的串、并联运用方式。

6.可根据管路布置的要求采用泵的竖式和横式安装。

性能参数

型号口径流量扬程转速电机功率
mmm3/hmr/minKW
15-80151.18.528000.18
1.58
27
20-110201.81628000.37
2.515
3.313.5
20-160201.83329000.75
2.532
3.330


25-110252.81629000.55
415
5.213.5
25-125252.820.629000.75
420
5.218
25-125A252.51729000.55
3.616
4.614.4
25-160252.83329001.5
432
5.230
25-160A252.62929001.1
3.728
4.926
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
32-100(I)324.413.229000.75
6.312.5
8.311.3
32-125323.52229000.75
520
6.518
32-125A323.117.629000.55
4.516
5.814.4
32-160(I)324.433.229002.2
6.332
8.330.2
32-200(I)324.450.529004
6.350
8.348
32-200A322.844.629002.2
444
5.242.7
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
40-100404.413.229000.55
6.312.5
8.311.3
40-100A403.910.629000.37
5.610
7.49
40-125404.42129001.1
6.320
8.318
40-125A403.917.629000.75
5.616
7.414.4
40-160404.43329002.2
6.332
8.330
40-160A404.12929001.5
5.928
7.826.3
40-160B403.825.529001.1
5.524
7.222.5
40-200404.45129004
6.350
8.348
40-200A404.14529003
5.944
7.842
40-200B403.73829002.2
5.336
734.5
40-250404.48229007.5
6.380
8.374
40-250A404.17229005.5
5.970
7.865
40-250B403.861.529004
5.560
756
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
40-100(I)408.813.229001.1
12.512.5
16.311.3
40-100(I)A40810.629000.75
1110
14.59
40-125(I)408.821.229001.5
12.520
16.317.8
40-125(I)A4081729001.1
1116
14.514
40-160(I)408.83329003
12.532
16.330
40-160(I)A408.22929002.2
11.728
15.226
40-160(I)B407.32329001.5
10.422
13.520.5
40-200(I)408.851.229005.5
12.550
16.348
40-200(I)A408.34529004
11.744
15.342
40-200(I)B407.53729003
10.636
13.834
40-250(I)408.881.2290011
12.580
16.377.5
40-250(I)A408.27129007.5
11.670
15.268
40-250(I)B407.661.429007.5
10.860
1458
40-250(I)C407.153.229005.5
1052
13.150.4
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
50-100508.813.629001.1
12.512.5
16.311.3
50-100A5081129000.75
1110
14.59
50-125508.821.529001.5
12.520
16.317.8
50-125A5081729001.1
1116
14.514
50-160508.83329003
12.532
16.330
50-160A508.22929002.2
11.728
15.226
50-160B507.32329001.5
10.422
13.520.5
50-200508.85229005.5
12.550
16.348
50-200A508.345.829004
11.744
15.342
50-200B507.53729003
10.636
13.834
50-250508.882290011
12.580
16.377.5
50-250A508.271.529007.5
11.670
15.268
50-250B507.661.429007.5
10.860
1458
50-250C507.153.229005.5
1052
13.150.4
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
50-100(I)5017.513.729001.5
2512.5
32.510.5
50-100(I)A5015.61129001.1
22.310
298.4
50-125(I)5017.521.529003
2520
32.518
50-125(I)A5015.61729002.2
22.316
2913.6
50-160(I)5017.534.429004
2532
32.527.5
50-160(I)A5016.43029004
23.428
30.424
50-160(I)B50152629003
21.624
2820.6
50-200(I)5017.552.729007.5
2550
32.545.5
50-200(I)A5016.446.429007.5
23.544
30.540
50-200(I)B5015.24029005.5
21.838
28.334.5
50-250(I)5017.582290015
2580
32.576.5
50-250(I)A5016.471.5290011
23.470
30.567
50-250(I)B501561290011
21.660
2857.4
50-315(I)5017.5128290030
25125
32.5122
50-315(I)A5016.6115290022
23.7113
31110
50-315(I)B5015.7103290018.5
22.5101
29.298
50-315(I)C5014.486290015
20.685
26.883
型号口径流量扬程转速电机功率
m3/hmr/minKW
65-1006517.513.729001.5
2512.5
32.510.5
65-100A6515.61129001.1
22.310
298.4
65-1256517.521.529003
2520
32.518
65-125A6515.61729002.2
22.316
2914.4
65-1606517.534.429004
2532
32.527.5
65-160A6516.43029004
23.428
30.424
65-160B65152629003
21.624
2820.6
65-2006517.552.729007.5
2550
32.545.5
65-200A6516.446.429007.5
23.544
30.540
65-200B6515.24029005.5
21.838
28.334.5
65-2506517.582290015
2580
32.576.5
65-250A6516.471.5290011
23.470
30.567
65-250B651561290011
21.660
2857.4
65-3156517.5127290030
25125
32.5122
65-315A6516.6115290022
23.7113
31110
65-315B6515.7103290018.5
22.5101
29.298
65-315C6514.486290015
20.685
26.883
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
65-100(I)653513.829003
5012.5
6510
65-100(I)A6531.31129002.2
44.710
588
65-125(I)65352229005.5
5020
6517
65-125(I)A6531.317.529004
44.716
5813.6
65-160(I)65353529007.5
5032
6528
65-160(I)A6532.730.629007.5
46.728
6124
65-160(I)B6530.32629005.5
43.324
56.321
65-200(I)653553.5290015
5050
6546
65-200(I)A6532.847290011
4744
6140
65-200(I)B6530.540.629007.5
43.538
56.633.4
65-250(I)653583290022
5080
6572
65-250(I)A6532.573290018.5
46.770
6163
65-250(I)B653062290015
43.360
5654
65-315(I)6535128290037
50125
65121
65-315(I)A6532.5112.6290030
46.5110
60.5106.4
65-315(I)B6531102.5290030
44.5100
5898
65-315(I)C652987290022
4185
53.683
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
80-100803513.829003
5012.5
6510
80-100A8031.31129002.2
44.710
588
80-12580352229005.5
5020
6517
80-125A8031.317.529004
4516
5813.6
80-16080353529007.5
5032
6528
80-160A8032.730.629007.5
46.728
6124
80-160B8030.32629005.5
43.324
56.321
80-200803553.5290015
5050
6546
80-200A8032.847290011
4744
6140
80-200B8030.540.629007.5
43.538
56.633.4
80-250803583290022
5080
6572
80-250A8032.573290018.5
46.770
6163
80-250B803062290015
43.360
5654
80-3158035128290037
50125
65122
80-315A8032.5112.6290030
46.5110
60.5107.4
80-315B8031102.5290030
44.5100
5898
80-315C802998290022
4185
53.683
80-3508035146290055
50150
65142
80-350A8031138.4290045
44.5142
58134.8
80-350B8029131.4290037
41135
53.6127.8
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
80-100(I)807013.629005.5
10012.5
13011
80-100(I)A8062.61129004
8910
1168.8
80-125(I)807023.5290011
10020
13014
80-125(I)A8062.61929007.5
8916
11611
80-160(I)807036.5290015
10032
13024
80-160(I)A8065.432290011
93.528
121.621
80-160(I)B8060.672290011
86.624
112.518
80-200(I)807054290022
10050
13042
80-200(I)A8065.447.5290018.5
93.544
121.637
80-200(I)B806141290015
8738
11332
80-250(I)807087290037
10080
13068
80-250(I)A8065.476290030
93.570
121.659.5
80-250(I)B806165290030
8760
11351
80-315(I)8070132290075
100125
130114
80-315(I)A8066.5119290055
95113
123.6103
80-315(I)B8063106.6290045
90101
11792
80-315(I)C805890290037
8285
10776
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
100-1001007013.629005.5
10012.5
13011
100-100A10062.61129004
8910
1168.8
100-1251007023.5290011
10020
13014
100-125A10062.61929007.5
8916
11611
100-1601007036.5290015
10032
13024
100-160A10065.432290011
93.528
121.621
100-160B10060.627290011
86.624
112.518
100-2001007054290022
10050
13042
100-200A10065.447.5290018.5
93.544
121.637
100-200B1006141290015
8738
11332
100-2501007037290037
10080
13068
100-250A10065.476290030
93.570
121.659.5
100-250B1006165290030
8760
11351
100-31510070132290075
100125
130114
100-315A10066.5119290055
95113
123.6103
100-315B10063106.6290045
90101
11792
100-315C1005890290037
8285
10776
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
100-100(I)1009614290011
16012.5
19210
100-125(I)1009624290015
16020
19214
100-125(I)A1008420290011
14017
16812
100-160(I)1009636290022
16032
19227
100-160(I)A1008432290018.5
14028
16823.5
100-200(I)1009653290037
16050
19245
100-200(I)A1008448290030
14045
16840
100-200(I)B1006043290022
10040
12036
100-250(I)1009683290055
16080
19272
100-250(I)A1008475290045
14072
16865
100-250(I)B1006068290037
10065
12058
100-35010060153.6290090
100150
120142
100-350A10061145.6290075
87142
113134
100-350B10058138.6290055
82135
107127
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
125-1001259613290011
16012.5
19212
125-100A1258610.429007.5
14310
1729.6
125-1251259622.6290015
16020
19217
125-125A1258618290011
14316
17213.6
125-1601259636290022
16032
19228
125-160A1259031.5290018.5
15028
18024.5
125-160B1258327290015
13824
16621
125-2001259655290037
16050
19246
125-200A1259048.4290030
15044
18040.5
125-200B1258341.3290022
13837.5
16634.5
125-2501259687290055
16080
19273
125-250A1259076290045
15070
18084
125-250B1258365290037
13860
16655
125-31512596133290090
160125
192119
125-315A12590117290075
150110
180104.6
125-315B12586106.4290075
143100
17295.2
125-315C12580.596290055
13488
16186
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
150-1251509622.6290011
16024
19217
150-125A150901829007.5
15016
18013.6
150-1601509636290022
16032
19227
150-160A1509032290018.5
15028
18023.5
150-160B1508427290015
14024
16821
150-20015014013.8145015
20012.5
26010.6
150-200A15012511145011
17610
232.58.5
150-200B1508441290022
14038
16834
150-25015014021.8145018.5
20020
26017
150-250A15012918.5145015
184.417
24014.4
150-250B15011715.2145011
16714
217.512
150-31515014033.8145030
20032
26028
150-315A15013129.5145022
18728
24324.5
150-315B15012125145018.5
17324
22521
150-35015096153.62900110
160150
192142.8
150-350A15090145.6290090
150142
180134.8
150-350B15084138.6290075
140135
168127.8
150-40015014053145045
20050
26044
150-400A15013146.6145037
18744
24338.3
150-400B15012240145030
17438
226.533
150-400C15011234145022
16032
20828
型号口径流量扬程转速电机功率
mmm3/hmr/minKW
150-250(I)15012087290075
20080
24072
150-250(I)A15011276290055
18770
22463
150-250(I)B15010465290045
17360
20854
150-315(I)1501201332900110
200125
240120
150-315(I)A150112116290090
187110
224105
150-315(I)B150104100290075
17395
20891
200-20020014013.8145015
20012.5
26010.6
200-200A20012511145011
17910
232.58.5
200-25020014021.8145018.5
20020
26017
200-250A20012918.5145015
184.417
24014.4
200-250B20011715.2145011


167

14
217.512

工作条件

1.吸入压力≤1.0MPa,或泵系统高工作压力≤1.6MPa,即吸入口压力+泵扬程≤1.6MPa、泵静压试验压力为≤2.5MPa,订货时请注明系统工作压力。泵系统工作压力大于1.6MPa时应在订货时另行提出,以便在制造时泵的过流部分和联接部分采用铸钢材料。

2.环境温度<40℃,相对湿度<40%。

3.所输送介质中固体颗粒体积含量不超过单位体积的0.1,粒度<0.2mm。

4.如果用介质为带有细小颗粒,请在订货时说明,以便本厂采用耐磨式机械密封。

注:由于产品技术改进参数可能有一定变化,公司不另行通知,请咨询公司技术部门索取新数据。

Hardware Design
关于我们                              产品中心                                行业资讯                             联系我们
QQ:374744223   3303543004  2875690581 联系传真:0577-67188873
联系地址:浙江省永嘉县六岙工业区
联系邮箱:zjswltkj@163.com
website qrcode

扫描查看手机版网站
